Leveling Staff
Product Details:
Product Description
Leveling Staves
We are offering a wide range of Leveling Staff. Our range of leveling staff is appreciated by our clients for its sturdy construction, wind resistance and fine coating. These open frame tripods are comes with lemon yellow powder coated and silver anodized. Wooden parts of the tripods are primed sealed surfaced and polished with touchwood. Telescopic tripod legs are of long grained free treated, aluminum or wood large or medium platform heat with adjustable central lock or side lock. There are clamps for batton shoes with solid tips.
Our range of leveling staff is customized as per the specifications of our clients. We manufacture a precision engineered range while making use of high grade raw material in a very competitive price.
Our range are includes :
- Aluminium Telescopic Levelling Staves
- Wooden Telescopic Levelling Staves
Specifications:
Leveling Staff Aluminum 4mt
Telescopic in canvas cover- 3 sec
Leveling Staff Aluminum 4mt :( Export Quality)
Telescopic in waterproof canvas cover- 4 sec closed length 1215mm
Graduation 5mm in front & 1mm back -
Width 5mm, thickness 27mm wt. 1.6kg
Leveling Staff Aluminum 5mt: Telescopic in canvas cover - 5 sec.With 1mm marking
Leveling Staff Aluminum 6mt: Telescopic in canvas cover - 5 sec. With 1mm marking
Leveling Staff Aluminum 6mt: Telescopic in canvas cover - 3 sec.
For more information call us on 0997304086
Technical Data :
Model | Extended Length (Mtr.) | Nos. of Sec. | Graduations (mm) | Width of the Sec. (mm) | Thick of the Sec. (mm) | Closed Length (mm) | Weight (Approx Kg.) | Package (Pcs. per Carton) |
AS-43 | 4 | 3 | 5 | 70 | 22 | 1600 | 1.500 | 10 |
AS-53 | 5 | 3 | 5 | 70 | 22 | 1900 | 1.950 | 6 |
AS-63 | 6 | 3 | 5 | 70 | 22 | 2300 | 2.400 | 6 |
WS-43 | 4 | 3 | 5 | 77 | 56 | 1660 | 3.500 | 6 |
WS-53 | 5 | 3 | 5 | 77 | 56 | 1960 | 4.200 | 6 |
