Product Description
RANGING ROD
We provide Ranging Rod that made of steel conduct pipe of 25mm dia.Alternatively painted internationa orange & white. Fitted with strong iron shoe at the bottom.
For more information call us on 0997304086
Sizes Available :
(a) Size 2 meter single(b) Size 3 meter single
(c) Size 2 meter 2 fold
(d) Size 3 meter 3 fold
TECHNICAL DATA
| Length | Extended | Nos. of | Diameter | Thickness of | Weight | Package |
Model | Per Sec. | Length | Sect. | of the Sect. | the Sect. | (Approx) | (Pcs. per |
| (Mtr) | (Mtr) |
| (mm) | (mm) | (Kg.) | Carton) |
R-1 | 1 | 2 | 2 | 25 | 1.5 | 0.750 | 10 |
R-2 | 1 | 3 | 3 | 25 | 1.5 | 1.150 | 10 |
R-3 | 1 | 2 | 2 | 25 | 1.5 | 1.250 | 10 |
R-4 | 1 | 3 | 3 | 25 | 1.5 | 1.650 | 10 |
R-5 | 1 | 2 | 2 | 31 | 1.5 | 1.150 | 10 |
R-6 | 1 | 3 | 3 | 31 | 1.5 | 1.700 | 10 |
R-7 | 1 | 2 | 2 | 31 | 1.5 | 1.900 | 10 |
R-8 | 1 | 3 | 3 | 31 | 1.5 | 2.500 | 10 |
