Vernier Transit Theodolites
Product Details:
Product Description
Vernier Transit Theodolites
Watts Theodolite is designed to meet the requirements of Civil Engineer, Surveyor and Mining Engineer for high grade instruments giving a maximum portability. Both circles are totally enclosed making the instruments suitable for work either above or below the ground. The instrument is supplied with standard accessories in teak wood box with aluminum telescopic tripod stand. Our range of products is subject to customization to meet the needs of our clients availed in very reasonable rates.
Watts theodolites is mainly used for:
Surveying and engineering work
Measuring angular values in a traverse or network
Determination of a line of sight along a level plane.
Technical Data :
Telescope | Model - 20 | Model - 10 |
Image | Erect | Erect |
Length | 178 mm | 178 mm |
Magnificaton | 25X | 25X |
Effective Aperture | 38mm | 38mm |
Field of View | 2.6 M at 100M | 2.6 M at 100M |
Short Focus | 1.5M | 1.5M |
Stadia Ratio | 1:100 | 1:100 |
Stadia Constant | 0 | 0 |
Resolving Power | 4" | 4" |
Circle Diameter | Hz113mm, V100 mm | Hz113mm, V100 mm |
Graduation | 20' | 10' |
Vernier Reading | 20" | 10" |
Plate Level Sensitivity | 45" / 2mm | 45" / 2mm |
Vertical Circle Level | 1' / 2mm | 1' / 2mm |
For more information Contact us 0997304086
